CSharp中TreeView绑定JSON数据

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22

{
    "accepttime": 1600966807,
    "certificate": "",
    "completetext": "",
    "completetime": 1601010419,
    "createtime": 1600966807,
    "deleteflag": 0,
    "endtimestr": "12:00",
    "gid": 42,
    "netbarCameraList": [{
        "account": "admin",
        "address": "172.16.36.17",
        "cameraid": 21,
        "gid": 42,
        "name": "36",
        "password": "52358",
        "port": 554
    }],
    "netbarname": "长沙",
    "uniacid": 6,
    "userid": 66
}

  1
  2
  3
  4
  5
  6
  7
  8
  9
 10
 11
 12
 13
 14
 15
 16
 17
 18
 19
 20
 21
 22
 23
 24
 25
 26
 27
 28
 29
 30
 31
 32
 33
 34
 35
 36
 37
 38
 39
 40
 41
 42
 43
 44
 45
 46
 47
 48
 49
 50
 51
 52
 53
 54
 55
 56
 57
 58
 59
 60
 61
 62
 63
 64
 65
 66
 67
 68
 69
 70
 71
 72
 73
 74
 75
 76
 77
 78
 79
 80
 81
 82
 83
 84
 85
 86
 87
 88
 89
 90
 91
 92
 93
 94
 95
 96
 97
 98
 99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164

/// <summary>
        /// 绑定树形控件
        /// </summary>
        /// <param name="treeView"></param>
        /// <param name="strJson"></param>
        public void BindTreeView(TreeView treeView, string strJson)
        {
            treeView.Nodes.Clear();
            if (IsJsonObject(strJson))//判断是否字典类型
            {
                JObject jo = (JObject)JsonConvert.DeserializeObject(strJson);
                foreach (var item in jo)
                {
                    TreeNode tree;
                    if (item.Value.GetType() == typeof(JObject))//判断是否为字典类型
                    {
                        tree = new TreeNode(item.Key);//以字典的键为节点名
                        AddTreeChildNode(ref tree, item.Value.ToString());
                        treeView.Nodes.Add(tree);
                    }
                    else if (item.Value.GetType() == typeof(JArray))
                    {
                        tree = new TreeNode(item.Key);
                        AddTreeChildNode(ref tree, item.Value.ToString());
                        treeView.Nodes.Add(tree);
                    }
                    else
                    {
                        tree = new TreeNode(item.Key + ":" + item.Value.ToString());
                        treeView.Nodes.Add(tree);
                    }
                }
            }
            if (IsArray(strJson))//判断是否为列表类型
            {
                JArray ja = (JArray)JsonConvert.DeserializeObject(strJson);
                int i = 0;
                foreach (JObject item in ja)
                {
                    TreeNode tree = new TreeNode();
                    foreach (var itemOb in item)
                    {
                        TreeNode treeOb;
                        if (itemOb.Value.GetType() == typeof(JObject))
                        {
                            treeOb = new TreeNode(itemOb.Key);
                            AddTreeChildNode(ref treeOb, itemOb.Value.ToString());
                            tree.Nodes.Add(treeOb);
                        }
                        else if (itemOb.Value.GetType() == typeof(JArray))
                        {
                            treeOb = new TreeNode(itemOb.Key);
                            AddTreeChildNode(ref treeOb, itemOb.Value.ToString());
                            tree.Nodes.Add(treeOb);
                        }
                        else
                        {
                            treeOb = new TreeNode(itemOb.Key + ":" + itemOb.Value.ToString());
                            tree.Nodes.Add(treeOb);
                        }
                    }
                    treeView.Nodes.Add(tree);
                }
            }
            treeView.ExpandAll();
        }
        /// <summary>
        /// 添加子节点
        /// </summary>
        /// <param name="parantNode"></param>
        /// <param name="value"></param>
        public void AddTreeChildNode(ref TreeNode parantNode, string value)
        {
            if (IsJsonObject(value))
            {
                JObject jo = (JObject)JsonConvert.DeserializeObject(value);
                foreach (var item in jo)
                {
                    TreeNode tree;
                    if (item.Value.GetType() == typeof(JObject))
                    {
                        tree = new TreeNode(item.Key);
                        AddTreeChildNode(ref tree, item.Value.ToString());
                        parantNode.Nodes.Add(tree);
                    }
                    else if (item.Value.GetType() == typeof(JArray))
                    {
                        tree = new TreeNode(item.Key);
                        AddTreeChildNode(ref tree, item.Value.ToString());
                        parantNode.Nodes.Add(tree);
                    }
                    else
                    {
                        tree = new TreeNode(item.Key + ":" + item.Value.ToString());
                        parantNode.Nodes.Add(tree);
                    }
                }
            }
            if (IsArray(value))
            {
                JArray ja = (JArray)JsonConvert.DeserializeObject(value);
                int i = 0;
                foreach (JObject item in ja)
                {
                    TreeNode tree = new TreeNode();
                    parantNode.Nodes.Add(tree);
                    foreach (var itemOb in item)
                    {
                        TreeNode treeOb;
                        if (itemOb.Value.GetType() == typeof(JObject))
                        {
                            treeOb = new TreeNode(itemOb.Key);
                            AddTreeChildNode(ref treeOb, itemOb.Value.ToString());
                            tree.Nodes.Add(treeOb);
                        }
                        else if (itemOb.Value.GetType() == typeof(JArray))
                        {
                            treeOb = new TreeNode(itemOb.Key);
                            AddTreeChildNode(ref treeOb, itemOb.Value.ToString());
                            tree.Nodes.Add(treeOb);
                        }
                        else
                        {
                            treeOb = new TreeNode(itemOb.Key + ":" + itemOb.Value.ToString());
                            tree.Nodes.Add(treeOb);
                        }
                    }
                }
            }
        }
        /// <summary>
        ///  判断是否JOjbect类型
        /// </summary>
        /// <param name="value"></param>
        /// <returns></returns>
        public bool IsJsonObject(string value)
        {
            try
            {
                JObject ja = JObject.Parse(value);
                return true;
            }
            catch (Exception ex)
            {
                return false;
            }
        }
        /// <summary>
        /// 判断是否JArray类型
        /// </summary>
        /// <param name="value"></param>
        /// <returns></returns>
        public bool IsArray(string value)
        {
            try
            {
                JArray ja = JArray.Parse(value);
                return true;
            }
            catch (Exception ex)
            {
                return false;
            }
        }
